Our designs

We'll be gradually building up the web catalogue. Starting with our tool for people who get their letters back to front.

When learning to read and write, many children are confused by the similarity of some letters and numbers. A common case is the letters b, d, p and q which are reflections and rotations of the same shape. For about 10% of the population difficulty reading and writing the correct letter persists into adulthood as dyslexia.
The stencil is a small aide-memoire which is kept at hand when writing. It has pictures of easily recognised objects that allow the user to correctly orientate the central hole for the target letter. Hopefully the user can then write the letter unaided with just the visual cue. If not, the stencil can be placed on the paper and used to guide the user's hand in tracing out the correct letter shape. This promotes muscle memory facilitating the mental link between the letter sound and the letter shape.
The tool has been tested in UK primary schools with positive results. Users and teachers have found that it is easy to use, helps to promote independence in writing and can be used discreetly enough to avoid embarrassment for the user.
Available for purchase in our shop and on Amazon and Ebay.

Consider the banana...

photo of a banana

...turn it around...

photo of the banana rotated

...flip it over. It's still a banana.

photo of the banana flipped upside down

Now consider the letter 'p'...

a large lower case letter p

...try flipping it over.

the letter p flipped over so it now looks like a lower case b

To many young children this is understandably very confusing.


child's handwriting with a reversed letter p


Almost 1 in 10 people experience dyslexia in adult life.

The letters b, d, p & q are reflections and rotations of the same shape. Consequently some learners have difficulty recognising them and telling them apart. For these people progress in reading and writing may be slow. The tool is an aide-memoire which can be kept close at hand when writing and is small enough to be discreet and to be carried around. It features pictures and accompanying labels on each face which have been chosen to contain graphemes (letters corresponding to phoneme sounds) which are taught early within all UK phonics schemes.

When writing, the user recognises the need for a, say, 'd' for dog sound. By turning over and/or rotating the stencil until the dog picture is showing the right way up, the correct letter is selected via the hole in the middle. Hopefully the user can then write the letter unaided with just the visual cue. If not, the stencil can be placed on the paper and used to guide the user's hand in tracing the letter out onto the paper.

injection moulded stencil writing aid with dimensions

The standard design is injection moulded from 2mm thick recycled nylon. It is manufactured in the UK using the waste stream from a local plastics factory. Using nylon creates a product that is smooth, strong, tough and easy to keep clean.

The design uses cartoonised representations of a bed, a dog, a pig and Queen Elizabeth II's head for the letters b, d, p and q. These correspond to words used in the UK primary education system to teach the target phoneme-grapheme correspondences.

Injection moulding creates a product that can be mass produced at both uniformly high quality and low unit cost. The product is recyclable at end of life through normal household recycling collection.

For other languages and cultures the design can be easily be adapted to different lettters, numbers and graphics and the seeks to protect the generality of these alternative embodiments. The tab discusses some of these alternative embodiments.

machined plywood stencil tool showing d side

Machined from plywood, this style of stencil has a nice feel in the hand, is biodegradable at end of life and can be produced in small numbers to suit local requirements.

Similar designs for other letter or number combinations (such as 'm' and 'w' or '6' and '9') can easily be produced to suit local requirements. Similarly for non-English languages, the graphics and text can be adapted. The also covers these use cases.

For alternative designs with large order volumes, recycled plastic injection moulding is the most economical production method. The disadvantage of injection moulding is that the relatively high tooling cost means that it only becomes economical for order volumes of more than about 3000 pieces. Alternative designs in smaller numbers can be produced by CNC machining from plywood. The image shows an example of the type of finish that can be produced. CNC machining has the advantage that the unit cost is broadly similar for order volumes of 1 to about 3000 pieces. However that unit cost is relatively high at around £4 per piece at the factory door.

The choice of material depends largely on the order volume so get in touch with your requirements via the Contact page and we can advise you on your best option.

Our intellectual property as inventors of these teaching tools is patent-pending protected under publication number GB2582939. The full patent document can be viewed at the European Patent Office website. The patent application seeks protection for the generality of stencil tools for learning writers with rotational and/or reflectional symmetry. This generality covers any combination of letters, numbers, graphics and manufacturing materials. Consequently if you partner with us to manufacture or sell these in the UK you aren't going to get undercut by copiers and end up in some race to the bottom on price and quality.
The particular embodiment shown here with the bed, dog, pig and queen words and graphics is also a UK Intellectual Propery Office registered design, number 6132152.

All the information in these tabs in one pdf document.Click the download icon to either view the brochure in your pdf viewer or save it to your device.
